CHEM

CHEM
SQ215 x H100mm 10W-18W IP65
LED Ceiling & Wall Light IP65

The CHEM Ceiling Light is finished by a robust surrounding frame made of cast aluminium protects the edges and corners of the frosted crystal glass with pattern, both indoor and outdoor with IP65. Its range of possible applications is also extended by its high protection class. And, It is able to be controlled by Dimmable Micorwave sensor  control , 0-10V and DALI.

Technical Data

  • Luminaire Type-

    安裝方式

    Tipo de luminaria

    Ceiling Mounted Type& Wall Mounted Type

    吸頂安裝&壁裝

    Tipo montado en el techo&Tipo montado en la pared

  • Power Consumption with LED Integral Driver

    LED燈具包括LED驅動電源功率

    Consumo de energía con controlador de LED

    • 10W
    • 18W



  • Input Voltage / 輸入電壓

    Voltaje de entrada

    AC100-240V 50/60HZ

  • LED Driver Type

    LED驅動款式

    Tipo de controlador LED

    Integrated-type LED Driver--Refer to LED driver specification 請參閱LED驅動器規格

    Consulte la especificación de controlador de LED

    1. ON/OFF Switch  AC100-240V 50/60HZ

    2. ZIGBEE Wireless Dimming Driver AC100-240V 50/60HZ

    3. 0 -10V Dimming Driver  AC100-240V 50/60HZ

    4. Dali Dimming Driver AC100-240V 50/60HZ



  • Control Protocol/控制協議

    Protocolo de Control

    0-10V / Dali / ZIGBEE Wireless Control

  • Power Factor / 功率因數/Factor de potencia

    PF>0.90

  • Total Harmonic Distortion/總諧波失/Distorsión armónica total

    THD<20%

  • LED Life-LED壽命-La vida del LED



    >60,000 hours

  • Color Temperature and Color

    色溫和顏色

    Temperatura y color del color

    2700K / 3000K / 4000K / 5000K / 6500K

  • Color Rendering Index-顯色指數

    Índice de reproducción cromática

     >82

  • MacAdam Ellipses Binning

    麥克亞當橢圓分級

    Mac Adam binning elipse



    Standard Deviation Colour Matching < 3 SDCM

    標準偏差配色< 3 SDCM

    Coincidencia de color estándar Desviación < 3 SDCM

  • Beam Angle

    光束角

    ángulo de haz

    120 °

  • Light Source Brand-光源品牌-Fuente de luz de marca

    SAMSUNG - ( Photobiological safety-IEC 62471 ‘Risk Group 1’ (low risk) )

  • "Lumen Maintenance LM-80 Reported by TM-21"

    1. L90(10k) = 50,700 hrs

    2. L80(10k) > 63,500 hrs

    3. L70(10k) > 63,500 hrs

  • uminaire Efficacy

    燈具效率

    La eficacia de la luminaria

    • 65 Lm/w(2700K),
    • 65 Lm/w(3000K),
    • 70 Lm/w(4000K),
    • 75 Lm/w(5000K),
    • 75 Lm/w(6500K),
  • LED Source Luminous Efficacy

    LED光源光效

    Fuente luminosa LED Eficacia

    • 100 Lm/w(2700K),
    • 100 Lm/w(3000K),
    • 105 Lm/w(4000K),
    • 120 Lm/w(5000K),
    • 120 Lm/w(6500K),
  • Housing materials

    外殼材料

    Materiales de la carcasa

    Die-cast aluminium and Frosted crystal glass with pattern

    壓鑄鋁和布紋鋼化玻璃

    Die fundición de aluminio y cristal esmerilado de vidrio con patrón

  • Housing Color

    外殼顏色

    color de la carcasa

    Dark Gray

    深灰色

    Dark Gray

  • Mech impact protection

    機械衝擊保護

    Protección contra impactos mecánicos

    IK10

  • Operating Temperature Range / 工作溫度範圍

    Rango de temperatura de funcion amiento

    -20 °C / +60 °C /  -4 °F / +124 °F

  • Operating Humidity -工作濕度

    Humedad de funcionamiento

    0~90%, non-condensing-不結霜

    sin condensación

  • Dimension

    尺寸

    Dimensión

    W: 215 x L: 215 x H: 100 mm

  • Weight

    重量

    Peso

    3.0 kg

  • Ingress Protection-防護等級

    Protección de ingreso

    IP65 - (IEC 60529)

  • Environment-使用環境-medio ambiente

    Outdoor

  • Comply Testing Standard

    符合測試標準

    Cumplir el estándar de prueba

    LED Luminaires: IEC 60598-1 / IEC 60598-2-2 / Photometric data-IES format

    LED Driver: EN 55015 / IEC 61000-3-2 / IEC 61347-1 / IEC 61347-2-13 / IEC 61547

  • Certification-認證-Certificación

Specification Code

Example Product Code:
CHEM-10W-SW-30
CHEM
-
POWER CONSUMPTION
-
LED DRIVER TYPE
-
COLOR TEMPERATURE

POWER CONSUMPTION

  • 10W
    10W
  • 18W
    18W

LED DRIVER TYPE

  • SW
    ON/OFF Switch
  • AN
    Analog 0 -10V Dimming
  • DA
    DALI Dimming
  • ZI
    ZIGBEE Wireless Control

COLOR TEMPERATURE

  • 27
    2700K
  • 30
    3000K
  • 40
    4000K
  • 50
    5000K
  • 65
    6500K

Technical Drawing
