- Ultra flexible design make it can be curved freely to achieve creative shapes like arch, circle, wave, customized size available.
- High transparent rate, easy for stage light, fog, lasers go through the screen to create superb visual effect.
- Fast inter-panel locks make it quick and easy to set up and dismantle large-scaled screen, no tools required.
- Quick hanging up by using the following two pieces of connector. Head and tail of the panel, with waterproof connectors
- Optional control system : DMX 512A or SPI
- UV resistance,UL V0 flame retardant grade
STILO
Technical Data
-
Pixel Dimension-像素尺寸-Dimensión
Dia 20 x H: 12 mm
-
Power Consumption Max-燈具功率
Consumo de energía Max
- 0.6W Per Pixel Max 154W/m² = 256pcs /m² @ P62.5mm
- 0.72W Per Pixel Max 185W/m² = 256pcs /m² @ P62.5mm
- 0.96W Per Pixel Max 246W/m² = 256pcs /m² @ P62.5mm
-
LED Pitch
LED像素間距
LED Pitch
- 62.5 mm
- 100 mm
- 120 mm
- 160 mm
- can be customized
-
Input Voltage-輸入電壓-Voltaje de entrada
- DC12V
-
Control Protocol-控制協議
Protocolo de Control
- DMX 512A
- SPI
-
Pixels & DMX Channels
像素和DMX 通道
Píxeles y canales DMX
- 1 PXL = 3 DMX Channels @ RGB
- 1 PXL = 4 DMX Channels @ RGBW
-
Beam Angle光束角ángulo de haz
120°
-
Light Source Brand-光源品牌-Fuente de luz de marca
- CREE
-
Color Resolution色彩分辨率
Resolución de color
3 x 16 bit (Gamma correction) 3 x 16位(伽瑪校正)
3 x 16 bits (corrección gamma)
-
LED Life-LED壽命-La vida del LED
>60,000 hours
-
Color 顏色 color
- RGB
- RGBW (3000K / 4000K / 5000K/ 6500K)
-
Color Rendering Index-顯色指數
Índice de reproducción cromática
> 80 @ White Color
-
Color Range
顏色範圍
Gama de colores
16.7 Million additive RGB colors
1670萬RGB顏色
16,7 millones de colores RGB aditivos
-
Luminaire Efficacy燈具效率La eficacia de la luminaria
- 22 Lm/w(RGB), 27lm/w (RGBW)
-
Brightness亮度Brillo
650 cd/m²
-
Housing materials-外殼材料
Materiales de la carcasa
Polycarbonate molding (Anti-UV and UL-V0 flame retardant protected)
PC 聚碳酸酯成型(防紫外線和UL-V0阻燃保護)
oldura de policarbonato (con protección ignífuga anti-UV y UL-V0)
-
Housing Color外殼顏色color de la carcasa
Flat Transparent 平面透明 Plano Transparente
-
Ingress Protection-防護等級
Protección de ingreso
IP67
-
Fireproof Grade 防火等級
Grado a prueba de fuego
UL94 -V0
-
UV Resistance Level抗紫外線等級
Nivel de resistencia a los rayos UV
4
-
Operating Humidity -工作濕度
Humedad de funcionamiento
0~90%, non-condensing-不結霜
sin condensación
-
Weight 重量 Peso
- 3g per Pixel 9kg per m²
-
Operating Temperature Range / 工作溫度範圍
Rango de temperatura de funcion amiento
-25 °C / +50 °C
Specification Code
Power Consumption
-
0.6W0.6W Per Pixel Max
-
0.75W0.72W Per Pixel Max
-
0.96W0.96W Per Pixel Max
